Customized K type thermocouple with stainless steel lead wire for injection mould
Description:
1) Thermocouples are manufactured in many different configurations for multitude of applications. Diameters, lengths, sheath material, lead lengths and sensor material are just a few of the variables that go into determining the style of thermocouple when manufactured. The main determining factors of what type thermocouple needs to be used in a application is temperature, environment, response time and accuracy. The junction of the thermocouple can be grounded, ungrounded or exposed.
2) Thermocouples are easy to use, Thermocouples are the most popular temperature sensors. They are cheap, interchangeable, have standard connectors and can measure a wide range of temperatures.
3) Thermocouple type:Assembly thermocouple, Armored thermocouple, bayonet spring fixed thermocouple,high temperature thermocouple, platinum and rhodium thermocouple,anti-corrosion thermocouple, wear-resistant thermocouple, high pressure thermocouple, special thermocouple, thermocouple, hand-held thermocouple, miniature thermocouple, noble metal thermocouple, rapid thermocouple, tungsten rhenium thermocouple, single core armored thermocouple etc.
Specification:
Please identify the following items when ordering:
1. Shutter support Specification
2. Single-ouch or double-ouch
3. Lead Wire Length
4. Lead Wire Material
5. Protection material
6. Protection length
7. Stainless steel armor tube material
8. Stainless steel armor tube length
9. Spring material, ID, OD and length
| Temperature material | Type | Graduation | Spec. of protection tube(mm) | Use temperature°C |
| Total Lenght | Length in fluid | external diameter of ceramic tube | Material of protection tube |
| PtRh10-Pt | WRP | S | 300 350 400 450 550 650 900 1150 1250 | 150 200 250 300 400 500 750 1000 1100 | φ16 φ25 | High Al content tube | 0-1300 |
| PtRh30-Ptrh6 | WRR | B | Corundum tube | 0-1600 |
| PtRh13-pT | WRQ | R | φ16 φ20 | High Al content tube | 0-1200 |
| Mini PtRh10-Pt | WRP-100 | S | 252 | 252 | φ7 | High Al content tube | 0-1200 |
Application:
- Hor runner system
- Plastic Industry
- Packaging Machinery
- Medical equipment
- Casting Process
- Other electric heating industry
Advantages:
- Specializes in manufacturing heater,thermocouple and equipment more than 15 years as well as export the relevant component.
- CE-marked products conform to PICC regulations
- ISO 9001:2008-certified factory quipped with heater lines
- Up to 200000 units turned out each month
- Custom orders welcome
- R&D team updates every month with 10 new items
- Sample take up to 3 days,but can be finished with one day in ugent cases
- GME heater can replace Hotset,GC-Heat,Kit,Euroheat,ROTFIL ect
- USA high purityMgo,Germany Nici8020 alloy wire,Germany fiberglass protection
